WELDWELL-6013 medium coated all position rutile electrodes is designed for high quality welding jobs on AC as well as on DC (-) Welding Current. Self sla. Easy slag detach ability and smooth weld bead. the weld metal properties meet the requirement of all international codes. Typical application includes light structural works, Storange Tank, Machinery Construction, Railway Coach and Wagon, Ship and for general repair and maintenance.
CLASSIFICATION & CODING |
CURRENT CONDITION D(±)A50 |
TYPICAL WELD METAL PROPERTIES |
|||||
|---|---|---|---|---|---|---|---|
| Size (mm) | Amps |
Chemical Composition |
Mechnical Properties |
||||
| Elements | % (Max) | ||||||
| 2.50 x 350 | 60-80 |
C | 0.10 | YS | 330 N/mm2 min | ||
| IS 814 : ER4211 x AWS, A5.1: E-6013 | 3.15 x 450 | 130-170 |
Mn | 0.65 | U.T.S | 410- 540 N/mm2 | |
| 4.00 x 450 | 180-230 |
S | 0.03 | Elongation | 22% min | ||
| 5.00 x 450 | 250 -330 |
P | 0.03 | Impact at 0oC | 47 Joules min | ||
| 6.30 x 450 | 250-330 |
Si | 0.30 | ||||
