Nayyar Electrodes Pvt. Ltd. SPARC 308L-SS

SPARC
308L-SS

DESCRIPTION & APPLICATIONS

SPARC-308L-SS is an extra low carbon rutile based 19 Cr, 10 Ni type stainless steel electrode for welding of unstablilised /stabilized 18/8 type stainless steels. resistant to atmospherice corrosion, 3 to 8 % Ferrite gives resistance to corrosion and cracking at temperature upto 700 c

Typical application includes welding of AISIL 301L, 302L, 304L,308L AND 347 grades adn normal carbon grades like 301,302,304,308 etc. Welding of household articles, hospital apparatus, diary and soap industries, nitric and acetic acid industries etc.

CLASSIFICATION & CODING
CURRENT CONDITION DC(+)/AC

TYPICAL WELD METAL PROPERTIES
  Size (mm)
Amps
Chemical Composition
Mechnical Properties
      Elements % (Max)
  2.00 x 350
30-50
C 0.04 max U.T.S 60 kgf/mm2
AWS/A5.4: E308L-16 IS:5206::E19.9LR 26 2.50 x 350
500-80
Mn 1.50 Elongation 40%
  3.15 x 350
80-110
Si 0.50 FN 3-8
  4.00 x 350
110-140
Cr 19.0 Impact (CVN) 7 Kgf at 27 C
  5.00 x 350
140-180
Ni 9.50
      S 0.03 max

P 0.04 max
